IP67 的防水设计，FUEGO PRO 地埋灯配备了防冷凝的专利设计，拥有对称以及非对称洗墙掠射和投射配光，独特的可调节装置，可进行现场出光方向调整，调整范围为 0°〜20°。24V 直流和 220V 交流两种接电版本可供选择。
| Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
| EIR1S | T Frameless | 07 7(Max) | 3 | 356 | ET ON-OFF 24V DC Power Supply MT DMX512 Dimming 24V DC Power Supply EL ON-OFF 220V AC Power Supply | S 8° 1 15° 2 25° 4 45° | 30 3000K 40 4000K | B Black |
| Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
| EIR1S | F Frame | 07 7(Max) | 3 | 356 | ET ON-OFF 24V DC Power Supply MT DMX512 Dimming 24V DC Power Supply EL ON-OFF 220V AC Power Supply | S 8° 1 15° 2 25° 4 45° | 30 3000K 40 4000K | S Stainless Steel |
示例：EIR1ST-07ET-S30-B
| 型号 | 光源功率（W） | 输入电压/电流 | 调光控制 | 光束角 | 色温（K） | 表面颜色 |
|---|---|---|---|---|---|---|
| EIR1SF-07ET-130-S | 7W | 24V DC | ON-OFF | 15° | 3000 | 不锈钢色 |
| EIR1SF-07ET-140-S | 7W | 24V DC | ON-OFF | 15° | 4000 | 不锈钢色 |
| EIR1SF-07ET-230-S | 7W | 24V DC | ON-OFF | 25° | 3000 | 不锈钢色 |
| EIR1SF-07ET-240-S | 7W | 24V DC | ON-OFF | 25° | 4000 | 不锈钢色 |
| EIR1SF-07ET-430-S | 7W | 24V DC | ON-OFF | 45° | 3000 | 不锈钢色 |
| EIR1SF-07ET-440-S | 7W | 24V DC | ON-OFF | 45° | 4000 | 不锈钢色 |
| EIR1SF-07ET-S30-S | 7W | 24V DC | ON-OFF | 8° | 3000 | 不锈钢色 |
| EIR1SF-07ET-S40-S | 7W | 24V DC | ON-OFF | 8° | 4000 | 不锈钢色 |
| EIR1SF-07ML-130-S | 7W | 220V AC/50Hz | ON-OFF | 15° | 3000 | 不锈钢色 |
| EIR1SF-07ML-140-S | 7W | 220V AC/50Hz | ON-OFF | 15° | 4000 | 不锈钢色 |
| EIR1SF-07ML-230-S | 7W | 220V AC/50Hz | ON-OFF | 25° | 3000 | 不锈钢色 |
| EIR1SF-07ML-240-S | 7W | 220V AC/50Hz | ON-OFF | 25° | 4000 | 不锈钢色 |
| EIR1SF-07ML-430-S | 7W | 220V AC/50Hz | ON-OFF | 45° | 3000 | 不锈钢色 |
| EIR1SF-07ML-440-S | 7W | 220V AC/50Hz | ON-OFF | 45° | 4000 | 不锈钢色 |
| EIR1SF-07ML-S30-S | 7W | 220V AC/50Hz | ON-OFF | 8° | 3000 | 不锈钢色 |
| EIR1SF-07ML-S40-S | 7W | 220V AC/50Hz | ON-OFF | 8° | 4000 | 不锈钢色 |
| EIR1SF-07MT-130-S | 7W | 24V DC | DMX512 Dimming | 15° | 3000 | 不锈钢色 |
| EIR1SF-07MT-140-S | 7W | 24V DC | DMX512 Dimming | 15° | 4000 | 不锈钢色 |
| EIR1SF-07MT-230-S | 7W | 24V DC | DMX512 Dimming | 25° | 3000 | 不锈钢色 |
| EIR1SF-07MT-240-S | 7W | 24V DC | DMX512 Dimming | 25° | 4000 | 不锈钢色 |
| EIR1SF-07MT-430-S | 7W | 24V DC | DMX512 Dimming | 45° | 3000 | 不锈钢色 |
| EIR1SF-07MT-440-S | 7W | 24V DC | DMX512 Dimming | 45° | 4000 | 不锈钢色 |
| EIR1SF-07MT-S30-S | 7W | 24V DC | DMX512 Dimming | 8° | 3000 | 不锈钢色 |
| EIR1SF-07MT-S40-S | 7W | 24V DC | DMX512 Dimming | 8° | 4000 | 不锈钢色 |
| EIR1ST-07ET-130-B | 7W | 24V DC | ON-OFF | 15° | 3000 | 黑色 |
| EIR1ST-07ET-140-B | 7W | 24V DC | ON-OFF | 15° | 4000 | 黑色 |
| EIR1ST-07ET-230-B | 7W | 24V DC | ON-OFF | 25° | 3000 | 黑色 |
| EIR1ST-07ET-240-B | 7W | 24V DC | ON-OFF | 25° | 4000 | 黑色 |
| EIR1ST-07ET-430-B | 7W | 24V DC | ON-OFF | 45° | 3000 | 黑色 |
| EIR1ST-07ET-440-B | 7W | 24V DC | ON-OFF | 45° | 4000 | 黑色 |
| EIR1ST-07ET-S30-B | 7W | 24V DC | ON-OFF | 8° | 3000 | 黑色 |
| EIR1ST-07ET-S40-B | 7W | 24V DC | ON-OFF | 8° | 4000 | 黑色 |
| EIR1ST-07ML-130-B | 7W | 220V AC/50Hz | ON-OFF | 15° | 3000 | 黑色 |
| EIR1ST-07ML-140-B | 7W | 220V AC/50Hz | ON-OFF | 15° | 4000 | 黑色 |
| EIR1ST-07ML-230-B | 7W | 220V AC/50Hz | ON-OFF | 25° | 3000 | 黑色 |
| EIR1ST-07ML-240-B | 7W | 220V AC/50Hz | ON-OFF | 25° | 4000 | 黑色 |
| EIR1ST-07ML-430-B | 7W | 220V AC/50Hz | ON-OFF | 45° | 3000 | 黑色 |
| EIR1ST-07ML-440-B | 7W | 220V AC/50Hz | ON-OFF | 45° | 4000 | 黑色 |
| EIR1ST-07ML-S30-B | 7W | 220V AC/50Hz | ON-OFF | 8° | 3000 | 黑色 |
| EIR1ST-07ML-S40-B | 7W | 220V AC/50Hz | ON-OFF | 8° | 4000 | 黑色 |
| EIR1ST-07MT-130-B | 7W | 24V DC | DMX512 Dimming | 15° | 3000 | 黑色 |
| EIR1ST-07MT-140-B | 7W | 24V DC | DMX512 Dimming | 15° | 4000 | 黑色 |
| EIR1ST-07MT-230-B | 7W | 24V DC | DMX512 Dimming | 25° | 3000 | 黑色 |
| EIR1ST-07MT-240-B | 7W | 24V DC | DMX512 Dimming | 25° | 4000 | 黑色 |
| EIR1ST-07MT-430-B | 7W | 24V DC | DMX512 Dimming | 45° | 3000 | 黑色 |
| EIR1ST-07MT-440-B | 7W | 24V DC | DMX512 Dimming | 45° | 4000 | 黑色 |
| EIR1ST-07MT-S30-B | 7W | 24V DC | DMX512 Dimming | 8° | 3000 | 黑色 |
| EIR1ST-07MT-S40-B | 7W | 24V DC | DMX512 Dimming | 8° | 4000 | 黑色 |
