FUEGO Compact Adjustable 可调角范围0°~30°，面框采用优质316 不锈钢，灯体铝压铸成型，高温粉末喷涂，适用于户外环境，IP67 防护等级， IK08 防冲击等级，可抗压 2000kg。配合预埋筒的设计，方便客户安装与维护。
在灯具表面即可轻松实现，水平 0-355°，垂直 0-30° 调节，现场安装调试更便捷、高效
Fuego Compact
Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EIR5S High Lumens | A Adjustable | 12 12(Max) | 8 | 997 | EL ON-OFF | S 7° 1 14° 2 20° 3 30° | 27 2700K 30 3000K 40 4000K | SS Stainless Steal |
Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EIR6S Super Comfort | A Adjustable | 12 12(Max) | 8 | 687 | EL ON-OFF | S 7° 1 13° 2 20° 3 30° | 27 2700K 30 3000K 40 4000K | SS Stainless Steal |
示例：EIR6SA-12EL-S27SS
| 型号 | 光源功率（W） | 输入电压/电流 | 调光控制 | 光束角 | 色温（K） | 表面颜色 |
|---|---|---|---|---|---|---|
| EIR5SA-12EL-127SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 2700 | 不锈钢色 |
| EIR5SA-12EL-130SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 3000 | 不锈钢色 |
| EIR5SA-12EL-140SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 4000 | 不锈钢色 |
| EIR5SA-12EL-227SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 2700 | 不锈钢色 |
| EIR5SA-12EL-230SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 3000 | 不锈钢色 |
| EIR5SA-12EL-240SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 4000 | 不锈钢色 |
| EIR5SA-12EL-327SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 2700 | 不锈钢色 |
| EIR5SA-12EL-330SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 3000 | 不锈钢色 |
| EIR5SA-12EL-340SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 4000 | 不锈钢色 |
| EIR5SA-12EL-S27SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 2700 | 不锈钢色 |
| EIR5SA-12EL-S30SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 3000 | 不锈钢色 |
| EIR5SA-12EL-S40SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 4000 | 不锈钢色 |
| EIR6SA-12EL-127SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 2700 | 不锈钢色 |
| EIR6SA-12EL-130SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 3000 | 不锈钢色 |
| EIR6SA-12EL-140SS | 12W | 220V AC/50Hz | ON-OFF | 13° | 4000 | 不锈钢色 |
| EIR6SA-12EL-227SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 2700 | 不锈钢色 |
| EIR6SA-12EL-230SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 3000 | 不锈钢色 |
| EIR6SA-12EL-240SS | 12W | 220V AC/50Hz | ON-OFF | 20° | 4000 | 不锈钢色 |
| EIR6SA-12EL-327SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 2700 | 不锈钢色 |
| EIR6SA-12EL-330SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 3000 | 不锈钢色 |
| EIR6SA-12EL-340SS | 12W | 220V AC/50Hz | ON-OFF | 30° | 4000 | 不锈钢色 |
| EIR6SA-12EL-S27SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 2700 | 不锈钢色 |
| EIR6SA-12EL-S30SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 3000 | 不锈钢色 |
| EIR6SA-12EL-S40SS | 12W | 220V AC/50Hz | ON-OFF | 7° | 4000 | 不锈钢色 |
