FUEGO Compact 面框采用优质316不锈钢，灯体铝压铸成型，高温粉末喷涂，适用于户外环境，IP67 防护等级， IK08 防冲击等级，可抗压 1500kg。配合预埋筒的设计，方便客户安装与维护。
Fuego Compact
Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EIR5T High lumens | A Adjustable | 06 6W(Max) | 3 | 455 | EL ON-OFF | S 6° 1 13° 2 20° 3 30° | 27 2700K 30 3000K 40 4000K | SS Stainless Steel |
Model | Comment | Power (W) | LEDs (Quantity) | Max Lumens (lm) | Control Systems | Beam | CCT | Finish |
EIR6T Super Comfort | A Adjustable | 06 6W(Max) | 3 | 349 | EL ON-OFF | S 6° 1 13° 2 20° 3 30° | 27 2700K 30 3000K 40 4000K | SS Stainless Steel |
示例：EIR6TA-06EL-127SS
| 型号 | 光源功率（W） | 输入电压/电流 | 调光控制 | 光束角 | 色温（K） | 表面颜色 |
|---|---|---|---|---|---|---|
| EIR5TA-06EL-127SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 2700 | 不锈钢色 |
| EIR5TA-06EL-130SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 3000 | 不锈钢色 |
| EIR5TA-06EL-140SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 4000 | 不锈钢色 |
| EIR5TA-06EL-227SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 2700 | 不锈钢色 |
| EIR5TA-06EL-230SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 3000 | 不锈钢色 |
| EIR5TA-06EL-240SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 4000 | 不锈钢色 |
| EIR5TA-06EL-327SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 2700 | 不锈钢色 |
| EIR5TA-06EL-330SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 3000 | 不锈钢色 |
| EIR5TA-06EL-340SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 4000 | 不锈钢色 |
| EIR5TA-06EL-S27SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 2700 | 不锈钢色 |
| EIR5TA-06EL-S30SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 3000 | 不锈钢色 |
| EIR5TA-06EL-S40SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 4000 | 不锈钢色 |
| EIR6TA-06EL-127SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 2700 | 不锈钢色 |
| EIR6TA-06EL-130SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 3000 | 不锈钢色 |
| EIR6TA-06EL-140SS | 6W | 220V AC/50Hz | ON-OFF | 13° | 4000 | 不锈钢色 |
| EIR6TA-06EL-227SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 2700 | 不锈钢色 |
| EIR6TA-06EL-230SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 3000 | 不锈钢色 |
| EIR6TA-06EL-240SS | 6W | 220V AC/50Hz | ON-OFF | 20° | 4000 | 不锈钢色 |
| EIR6TA-06EL-327SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 2700 | 不锈钢色 |
| EIR6TA-06EL-330SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 3000 | 不锈钢色 |
| EIR6TA-06EL-340SS | 6W | 220V AC/50Hz | ON-OFF | 30° | 4000 | 不锈钢色 |
| EIR6TA-06EL-S27SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 2700 | 不锈钢色 |
| EIR6TA-06EL-S30SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 3000 | 不锈钢色 |
| EIR6TA-06EL-S40SS | 6W | 220V AC/50Hz | ON-OFF | 6° | 4000 | 不锈钢色 |
